This page provides links to a range of resources to support your use of Causeway SignPlot and Causeway SignLoad – including technical documents, free software tools, and sign graphics.
Resources also include graphics developed for Transport Scotland’s 2022 amendment to TSRGD, available in both Causeway SignPlot and DXF formats.
Additional Tools for Causeway SignPlot and Causeway SignLoad Users
We offer two free software tools to support traffic sign design and assessment: Causeway SignPlot Sign Illumination Tool and Causeway SignLoad Designer. These are available to download at no cost and are designed to help users work in line with UK standards, including TSRGD and BS EN specifications.
Causeway SignPlot Illumination Tool
For TSRGD 2016. Answers that tricky question: does this sign legally need lighting or reflectorisation?
New: version 1.10 covers the 2022 Scottish Amendments for LEX signs, etc.
Causeway SignLoad Designer
Steel support design for traffic signs to BS EN 12899-1:2007. Checks also for passive safety to BS EN 12767:2019.
New: version 3.4 covers multiple signs on the same structure.
Downloadable Sign Graphics – Transport Scotland 2022 Amendment
As part of our work with Transport Scotland, we developed a set of sign graphics to support their amendment TSRGD that came into force on 23 May 2022.
These files are available in both SignPlot and DXF formats. You can download them by pressing the links below – please note that the files will begin downloading automatically. If you have any issues accessing the files, please don’t hesitate to contact our support team via the Support Portal.
Click here to download SignPlot format
Click here to download DXF format
Additional resources and links
You’ll find a broader selection of sector-specific materials on our additional resources page, including official guidance documents, working drawings, traffic sign regulations, mapping resources and reference material from organisations such as the Department for Transport, Transport Scotland, National Highways, and the Institute of Highway Engineers.
If you’re a user of Causeway SignPlot, Causeway SignLoad, Causeway ParkMap or Causeway AccsMap, you can also access our dedicated user area – a secure, login-only space with further resources to support your use of the software.
Explore the full collection of public resources available on our website here, or log in here to discover even more tailored content.
